PHILIPS LUMILEDS

LED部品デバイス　単色・砲弾型

LUXEON 3535L Colors
LUXEON C Colors
LUXEON Rebel Colors
LUXEON Z Color Line
LUXEON 3535L Color Line
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON-C-Colors-Group L135-R625003500000 赤 620 630 10.0 13.5 お問い合わせ
L135-O615003500000 濃いオレンジ 610 620 13.0 15.5
L135-A589003500000 PCアンバー - - 24.0 35.0
L135-L567003500000 ライム - - 44.0 56.0
L135-G525003500000 緑 520 540 21.0 23.0
L135-B475003500000 青 469 480 8.2 11.0
LUXEON 3535L Colors
LUXEON C Colors
LUXEON Rebel Colors
LUXEON Z Color Line
LEXEON C Color Line
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON-C-Colors-Group L1C1-RED1000000000 赤 624 634 35 39 お問い合わせ
L1C1-RNG1000000000 濃いオレンジ 614 624 45 52
L1C1-PCA1000000000 PCアンバー - - 80 94
L1C1-GRN1000000000 緑 520 540 90 97
L1C1-CYN1000000000 シアン 490 510 65 72
L1C1-BLU1000000000 青 465 485 25 37
L1C1-RYL1000000000 ロイヤルブルー 440 460 480 532
LUXEON 3535L Colors
LUXEON C Colors
LUXEON Rebel Colors
LUXEON Z Color Line
LUXEON Rebel and LUXEON Rebel ES Colors
(LUXEON Rebel Colors product performance at 350mA)
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)		 Typical Efficacy (lm/W)or
Radiant Efficacy (%)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON Rebel and LUXEON Rebel ES LXM3-PD01 深い赤 650 670 260 290 37% お問い合わせ
LXM3-PD01 650 670 300 320 41%
LXM3-PD01 650 670 350 360 46%
LXML-PD01-0030 赤 620 645 30 38 37
LXML-PD01-0040 620 645 40 46 47
LXM2-PD01-0040 620 645 40 48 65
LXML-PD01-0050 620 645 50 52 53
LXM2-PD01-0050 620 645 50 53 75
LXM5-PD01 620 645 50 54 73
LXM2-PD01-0060 620 645 60 62 83
LXM5-PD01 620 645 60 64 87
LXM5-PD01 620 645 70 72 98
LXM5-PD01 620 645 80 82 112
LXM5-PH01 濃いオレンジ 610 620 50 53 72
LXML-PH01-0050 610 620 50 56 57
LXML-PH01-0060 610 620 60 62 63
LXM5-PH01 610 620 60 62 84
LXM2-PH01-0060 610 620 60 67 91
LXM2-PH01-0070 610 620 70 72 98
LXM5-PH01 610 620 70 74 101
LXM5-PH01 610 620 80 82 112
LXML-PL01-0030 アンバー 584.5 594.5 30 38 37
LXML-PL01-0040 584.5 594.5 40 48 46
LXM5-PL01 584.5 594.5 50 52 71
LXML-PL01-0050 584.5 594.5 50 54 51
LXML-PL01-0060 584.5 594.5 60 61 60
LXM5-PL01 584.5 594.5 60 64 87
LXM5-PL01 584.5 594.5 70 72 98
LXM5-PL01 584.5 594.5 80 83 113
LXM2-PL01-0000 PCアンバー 587.8 592 80 86 80
LXM2-PL01-0000 587.8 592 90 95 89
LXM2-PL01-0000 587.8 592 100 102 96
LXM2-PL01-0000 587.8 592 110 112 105
LXML-PX02-0000 ライム 566 569 140 148 154
LXML-PX02-0000 566 569 150 157 163
LXML-PX02-0000 566 569 160 167 174
LXML-PX02-0000 566 569 170 174 181
LXML-PX02-0000 566 569 180 183 190
LXML-PX02-0000 566 569 190 192 201
LXML-PM01-0070 緑 520 540 70 79 78
LXML-PM01-0080 520 540 80 88 86
LXML-PM01-0090 520 540 90 95 93
LXML-PM01-0100 520 540 100 102 100
LXML-PE01-0060 シアン 490 515 60 97 66
LXML-PE01-0070 490 515 70 76 75
LXML-PE01-0080 490 515 80 83 81
LXML-PB01-0018 青 460 485 18.1 22 21
LXML-PB01-0023 460 485 23.5 28 26
LXML-PB01-0030 460 485 30 35 33
LXML-PB01-0040 460 485 40 41 38
LXML-PR01-0500 ロイヤルブルー 440 460 500 520 48%
LUXEON Rebel and LUXEON Rebel ES Colors
(LUXEON Rebel Colors product performance at 350mA)
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)		 Typical Efficacy (lm/W)or
Radiant Efficacy (%)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON Rebel and LUXEON Rebel ES LXML-PB02 青 460 485 50 58 28 お問い合わせ
LXML-PB02 460 485 60 67 32
LXML-PB02 460 485 70 75 36
LXML-PB02 460 485 80 83 40
LXML-PR02-A900 ロイヤルブルー 440 460 900 1030 49%
LXML-PR02-0800 440 460 800 890 42%
LXML-PR02-0900 440 460 900 940 44%
LXML-PR02-0950 440 460 950 970 46%
LXML-PR02-1000 440 460 1000 1030 49%
LXML-PR02-1050 440 460 1050 1070 51%
LXML-PR02-1100 440 460 1100 1120 53%
LUXEON 3535L Colors
LUXEON C Colors
LUXEON Rebel Colors
LUXEON Z Color Line
LUXEON Z Color Line
(LUXEON Z Colors product performance at 500mA,Tj=25°C.)
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON Z Color Line LXZ1-PA01 深い赤 650 670 300 325 お問い合わせ
LXZ1-PA01 650 670 350 375
LXZ1-PD01 赤 620 645 40 44
LXZ1-PD01 620 645 48 52
LXZ1-PD01 620 645 56 60
LXZ1-PH01 濃いオレンジ 610 620 56 60
LXZ1-PH01 610 620 64 68
LXZ1-PH01 610 620 72 76
LXZ1-PL01 PCアンバー 585 590 48 52
LXZ1-PL01 585 590 56 60
LXZ1-PL01 585 590 64 68
LXZ1-PM01 緑 520 540 80 84
LXZ1-PM01 520 540 88 92
LXZ1-PM01 520 540 96 100
LXZ1-PM01 520 540 104 108
LXZ1-PE01 シアン 490 510 48 52
LXZ1-PE01 490 510 56 60
LXZ1-PE01 490 510 64 68
LXZ1-PB01 青 460 480 24 28
LXZ1-PB01 460 480 32 36
LXZ1-PB01 460 480 40 44
LXZ1-PR01 ロイヤルブルー 440 460 500 525
LXZ1-PR01 440 460 550 575
LXZ1-PR01 440 460 600 625
LUXEON Z Color Line
(LUXEON Z Colors product performance at 500mA,Tj=85°C.)
概形 型番 色 Dominant or Peak
Wavelength (nm)		 Luminous Flux (lm) or
Radiometric Power (mW)

お問い合わせ
Minimum Maximum Minimum Typical
LUXEON Z Color Line LXZ1-PA01 赤 624 634 24 28 お問い合わせ
LXZ1-PA01 624 634 32 36
LXZ1-PA01 624 634 40 44
LXZ1-PA01 624 634 48 52
LXZ1-PD01 濃いオレンジ 614 624 40 44
LXZ1-PD01 614 624 48 52
LXZ1-PD01 614 624 56 60
LXZ1-PH01 アンバー 594 604 16 20
LXZ1-PH01 594 604 24 28
LXZ1-PH01 594 604 32 36
LXZ1-PL01 PCアンバー 585 592 72 76
LXZ1-PL01 588 592 80 84
LXZ1-PL01 588 592 88 92
LXZ1-PL01 588 592 96 100
LXZ1-PL01 588 590 104 110
LXZ1-PM01 ライム 566 569 144 149
LXZ1-PM01 566 569 154 159
LXZ1-PM01 566 569 164 169
LXZ1-PM01 566 569 174 179
LXZ1-PM01 5566 569 184 189
LXZ1-PM01 566 569 194 199
